No.274
PUMMEL TESTER
Overview of PUMMEL TESTER
This tester is for evaluating the bondage of PVB film fragments inside safety glass composites used for automobiles.
The glass is constantly impacted by hammer while moving in an S shape.
The specimen is then evaluated according to the Pummel value by the level of exposed PVB surface.
Operation VIDEO
Specification
| Specifications are subject to change without notice. | |
|---|---|
| Test Specimen | 305 × 160 × 2.5 to 10 mm |
| Hammer | Striking Method： Hammer Striking Down Method + Assist Spring Impact Adjustment： Spring Screw Adjust Method |
| Horizontal Distance | Stroke: 150 mm |
| Vertical Distance | Stroke: 90 mm |
| Testing Speed | Approx. 120 sec. for 1 pc |
| Other Standard Specification | Room Light, Blank Shot Prevent System (Specimen Detect Sensor) |
| Power Source | AC 200 V, 3-Phase, 10 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | Main Body: W880 × D1,100 × H1,164 mm, 620 kg Control Box: W250 × D700 × H1,130 mm, 60 kg |
