No.360
CURL-SIZE TESTER
Overview of CURL-SIZE TESTER
This tester is used to measure the curl size and the degree of curl of paper.
The operator is to damp one side of the paper and measure the time it curled to its maximum size.
The tester is usually used on test specimens that are applied for printing papers.
Reference Standards
TAPPI-(T466), J.TAPPI-No.14
Specification
| Specifications are subject to change without notice. | |
|---|---|
| Specimen | W38 mm, L38 to 70 mm |
| Float | W0 to 25.4 mm (Adjustable), D50.8 mm |
| Angle Scale | 30 to 60° (Scale 1°) |
| Accessories | Specimen Mold |
| Dimensions/ Weight (Approx.) | W230 × D160 × H110 mm/ 3 kg |
