No.528
SUTHERLAND TYPE RUB TESTER
Overview of SUTHERLAND TYPE RUB TESTER
This tester is used to evaluate the feathering of paper and also abrasion endurance and color transfer characteristic of planographic ink.
Attaching the abrading paper and after it has been abraded, the operator is to check the abrading surface to evaluate the characteristics of the test specimen.
Reference Standards
JIS K5701-1
Specification
| Specifications are subject to change without notice. | |
|---|---|
| Specimen | 100 × 200 mm |
| Rubbing Paper | 50 × 200 mm |
| Rubbing Head | (25.4 ± 0.2) × (50.8 ± 0.2) mm (2 faces), Rubber T8 mm, Mass 908 ± 10 g |
| Additional Weight | 908 ± 10 g |
| Rubbing Distance | 57 ± 1 mm, Circular Arc R185 mm |
| Rubbing Speed | 43 ± 2 times/min |
| Counter | 6 Digits Preset Counter 6 Digits Running Counter |
| Power Source | AC 100 V, 1-Phase, 10 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | W310 × D720 × H370 mm, 46 kg |
