No.541 GARDNER TYPE FALLING SAND ABRASION TESTER
JIS A5423、H8503、H8682-3、ASTM D968
- This tester is used to evaluate the abrading endurance of paint and plate coated film surface.
- Dropping the standard testing sand from a prescript height to the test specimen which is attached at a 45°angle, the operator is to measure the amount of sand and time it took for the surface of the coated film to be exposed.
Specification
| Specifications are subject to change without notice. | |
| Funnel | Opening φ8″, Opening Angle 60° |
| Guide Pipe | Inner Diameter φ0.75″ |
| Specimen Setting Angle | 45° |
| Standard Sand | Carborundum, Grit #24 |
| Falling Height | 37″ (940 mm) |
| Falling Speed | 21 to 23.5 sec/ 2ℓ |
| Accessories | Specimen Setting Gauge, Jug, Lighting Device |
| Option | Architectual Material Spec (Hoppa Rotating Device, Specimen Retaining Device) |
| Power Source | AC 100 V, 1-Phase, 1 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | W360 × D320 × H1,650 mm, 35 kg |
