No.409 Water Penetration Resistance Tester For Textile｜For the tester to conduct a water penetration test

Overview of WATER PENETRATION RESISTANCE TESTER FOR TEXTILE

This tester is to conduct a water penetration test (hydrostatic fluid pressure method and A method, the low water pressure).
Tightening the test specimen to the clamp and raising the water level at a constant speed, the operator is to measure the water level when the water comes out from 3 places of the back side of the test specimen.
The tester can also conduct constant water pressure method and water leakage method.

Reference Standards

JIS L1092, ISO 811

Specification

Specifications are subject to change without notice.
Water Column	1 m or 1.5 m
Manometer	1,000 mmH2O or 1,500 mmH2O (Scale 1 mmH2O)
Pressing Speed	10 ± 0.5 cm/min or 60 ± 3 cm/min
Specimen	150 × 150 mm
Clamp	Inner Diameter φ113 mm (Effective Area 100 cm2)
Power Source	AC 100 V, 1-Phase, 3 A, 50/60 Hz
Dimensions/ Weight (Approx.)	1m spec:  W600 × D400 × H1,670 mm, 125 kg
