No.170 CLASH-BERG TORSION FLEXIBILITY TESTER (MANUAL)
JIS (K6734), (K6745), K6924-2, ASTM D1043, ISO 458
- This tester is used to measure the softening temperature of plastic.
- The test specimen is to be attached to the upper and lower Chucks of the tester and then dipped into water which the temperature is raised at a constant speed.
- At every 5 °C the water temperature has rises, the operator is to leave the test specimen untouched for 3 minutes.
- After the 3 minutes have passed, twisting torque is to be added to the test specimen so that the rigidity coefficient can be calculated from the twisting angle.
- The softening temperature will be acquired from the temperature-rigidity coefficient curving line.
Specification
| Specifications are subject to change without notice. | |
| Model | No.170 CLASH-BERG TORSION FLEXIBILITY TESTER (MANUAL) |
| Specime | W6.35 ± 0.03 mm, L64 mm, T0.8 to 1.5 mm |
| Chuck Distance | 40 mm |
| Angle Scale | 0 to 360° (Scale 1°) *Max. Angle 270° |
| Temperature Range | -60 to 100 °C (Dry Ice Cooling) |
| Heat-Up Speed | 2 °C/min |
| Torque Device | Pulley Type |
| Weight | 5 g, 10 g, 20 g, 50 g |
| Software | ― |
| Accessories | Duwar Flask, Thermometer: 2 pcs, Specimen Setting Gauge |
| Power Source | AC 100 V, 1-Phase, 10 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | W300 × D400 × H900 mm, 36 kg |
No.170-AUTO CLASH-BERG TORSION FLEXIBILITY TESTER (AUTOMATIC)
JIS (K6734), (K6745), K6924-2, ASTM D1043, ISO 458
- This tester reads the twisting angle of the test specimen by encoder to calculate the rigidity coefficient.
- The temperature-rigidity coefficient curving line will be displayed on the PC to acquire the softening temperature.
Specimen
| Specifications are subject to change without notice. | |
| Model | No.170-AUTO CLASH-BERG TORSION FLEXIBILITY TESTER (AUTOMATIC) |
| Specimen | W6.35 ± 0.03 mm, L64 mm, T0.8 to 1.5 mm |
| Chuck Distance | 40 mm |
| Angle Scale | 0 to 270° (Scale 1°) Detection: Rotary Encoder |
| Temperature Range | -60 to 100 °C (Dry Ice Cooling) |
| Heat-Up Speed | 2 °C/min |
| Torque Device | Pulley Type |
| Weight | 5 g, 10 g, 20 g, 50 g |
| Software | Windows Compatible |
| Accessories | Duwar Flask, Thermometer: 2 pcs, Specimen Setting Gauge |
| Power Source | AC 100 V, 1-Phase, 10 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | Tester Body: W320 × D400 × H1,230 mm, 50 kg Control Box: W350 × D460 × H355 mm, 17 kg |
No.312 TABER TYPE STIFFNESS TESTER
JIS P8125、TAPPI-T489、ISO 2493
- This tester is used to evaluate the stiffness of paper board according to the load bending method.
- Fixing one end of the test specimen and bending it 7.5° or 15° at a constant speed.
- The operator is to acquire the bending moment when the loading length reaches 50 mm.
Specification
| Specifications are subject to change without notice. | |
| Model | No.312 TABER TYPE STIFFNESS TESTER |
| Moment | Max. 490 mN⋅m (5,000 gf⋅cm) |
| Load Scale | Left-Right 0 to 100 |
| Weight Load | 100 gf, 200 gf, 500 gf |
| Load Position | 100 mm from the Pivot |
| Bending Angle | Left-Right 15° or 7.5° |
| Bending Speed | 180 ± 40°/min |
| Specimen | W30 to 40 mm (Standard: 38.0 ± 0.2 mm), L 70 mm, T3.2 mm or Less |
| Roller | φ8.60 ± 0.05 mm for Test φ8.93 ± 0.05 mm for Positioning |
| Power Source | AC 100 V, 1-Phase, 3 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | W300 × D350 × H500 mm, 25 kg |
No.312-D TABER TYPE STIFFNESS TESTER (DIGITAL)
JIS P8125、TAPPI-T489、ISO 2493
- This is the digital model of the TABER STIFFNESS TESTER where the stiffness of paper board can be directly read.
- The stiffness level will be indicated in mN-m terms.
- The tester can also calculate the resistance to bending (mN).
Specification
| Specifications are subject to change without notice. | |
| Model | No.312-D TABER TYPE STIFFNESS TESTER (DIGITAL) |
| Moment | Max. 490 mN⋅m (5,000 gf⋅cm) |
| Load Scale | Left-Right 0 to 100 |
| Weight Load | 100 gf, 200 gf, 500 gf |
| Load Position | 100 mm from the Pivot |
| Bending Angle | Left-Right 15° or 7.5° |
| Bending Speed | 180 ± 40°/min |
| Specimen | W30 to 40 mm (Standard: 38.0 ± 0.2 mm), L 70 mm, T3.2 mm or Less |
| Roller | φ8.60 ± 0.05 mm for Test φ8.93 ± 0.05 mm for Positioning |
| Power Source | AC 100 V, 1-Phase, 3 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | W300 × D350 × H520 mm, 25 kg |
No.342 CLARK TYPE STIFFNESS TESTER
JIS (L1018)、L1096、P8143、TAPPI-(T451)
- This tester is used to evaluate the stiffness of paper, plastic film, and textile according to the Clark’s method.
- The operator is to clip the test specimen between the 2 rolls and rotate it left and right until the test specimen falls over 90°.
- When the test specimen falls over 90° the operator is to measure the brattish length to calculate the stiffness.
Specification
| Specifications are subject to change without notice. | |
| Specimen | Paper: W15 to 50 mm (Standard 30 mm), L75 mm or More Textile: W20 mm, L150 to 200 mm |
| Roller | φ29.0 ± 1.0 mm |
| Angle Scale | Left-Right 0 to 90° (Scale 1°) |
| Chuck Rotation Speed | 1.0 ± 0.1 rpm (Manual) |
| Dimensions/ Weight (Approx. | W160 × D170 × H210 mm, 3 kg |
No.118 OLSEN TYPE STIFFNESS TESTER (HEAVY LOAD TYPE)
JIS K7106, ASTM D747
- This tester is used to measure the bending stiffness of plastic.
- The bending stiffness that can be tested with this tester is the apparent elastic modulus obtained from the cantilever test specimen and the bending angle.
Specification
| Specifications are subject to change without notice. | |
| Model | No.118 OLSEN TYPE STIFFNESS TESTER (HEAVY LOAD TYPE) |
| Moment | Max. 5 lb⋅in (1 lb = 453 g) |
| Load Scale | 0 to 100 % (Scale 1 %) |
| Weight | 0.5 lb: 1 pc, 1 lb: 2 pcs |
| Load Position | 4″ from Pivot |
| Angle Scale | 0 to 90° (Scale 1°) |
| Chuck Rotation Speed | 60°/min |
| Specimen | W5 ± 0.5 mm or 13 ± 0.5 mm, L60 mm or more, T1.0 ± 0.1 mm or T2.0 ± 0.2 mm |
| Support Length | 7 to 50 mm |
| Chuck Width | 30 mm |
| Power Source | AC 100 V, 1-Phase, 5 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | W340 × D300 × H460 mm, 10 kg |
No.118-D OLSEN TYPE STIFFNESS TESTER (HEAVY LOAD TYPE) (DIGITAL)
JIS K7106、ASTM D747
- This is the digital version of the OLSEN TYPE STIFFNESS TESTER.
- It is equipped with a calculating device that can calculate the average and standard deviation values of the test result.
Specification
| Specifications are subject to change without notice. | |
| Model | No.118-D OLSEN TYPE STIFFNESS TESTER (HEAVY LOAD TYPE) (DIGITAL) |
| Moment | Max. 5 lb⋅in (1 lb = 453 g) |
| Load Scale | 0 to 100 % (Scale 1 %) |
| Weight | 0.5 lb: 1 pc, 1 lb: 2 pcs |
| Load Position | 4″ from Pivot |
| Angle Scale | 0 to 90° (Scale 1°) |
| Chuck Rotation Speed | 60°/min |
| Specimen | W5 ± 0.5 mm or 13 ± 0.5 mm, L60 mm or more, T1.0 ± 0.1 mm or T2.0 ± 0.2 mm |
| Support Length | 7 to 50 mm |
| Chuck Width | 30 mm |
| Power Source | AC 200 V, 1-Phase, 3 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | W570 × D350 × H490 mm, 15 kg |
