Evaluating crease-flex resistance of woven and coated fabrics | SCOTT TYPE CREASE-FLEX ABRASION TESTER / No.433

Overview of SCOTT TYPE CREASE-FLEX ABRASION TESTER

This tester is used to conduct a crease-flex abrasion test on textile, rubber, and plastic according to the Scott type method.
The operator is to evaluate the abrading strength of the test specimen by measuring the number of times that it took for the test specimen to have a 10 to 15 mm wide cutline when a constant pressure force is added.
The loading method is spring type.

Reference Standards

JIS K604-4, (K6404-6), L1096, JASO

Specification

Specifications are subject to change without notice.
Specimen	25×120 mm
Clamp Distance	0–50 mm (standard distance 20 mm)
Press Load	4.9–49 N (0.5–5 kgf), spring load (standard load 9.81 N)
Rubbing Distance	0–60 mm (standard distance 40 mm)
Rubbing Speed	120 ± 2 cycles/min
Counter	6-digit preset counter
Option	Safety cover
Power Source	AC 100 V 1-phase 15 A 50/60 Hz
Dimensions and Weight (Approx.)	W465×D500×H460 mm, 60 kg

*A 2-station model is also available.
