No.429
OLSEN TYPE STIFFNESS TESTER
(FOR LIGHT LOAD)
Overview of OLSEN TYPE STIFFNESS TESTER (FOR LIGHT LOAD)
This tester is used to evaluate the bending reaction strength of stiff textile according to the bending method.
Fixing one end of the test specimen to the Chuck and bending the test specimen to a prescript shift degree, the operator is to measure the bending moment that is added to the other end.
Reference Standards
JIS K7106, (L1018), L1096, ASTM D747
Specification
| Specifications are subject to change without notice. | |
|---|---|
| Load Scale | 0 to 100 % (Scale 1 %) |
| Weight | 1/4 oz, 1/2 oz, 1 oz, 2 oz, 4 oz, 8 oz 〈1 oz = 28.3 g〉 |
| Load Position | 1⋅1/2″ and 3″ from Pivot |
| Angle Scale | 0 to 90° (Scale 1°) |
| Chuck Rotation Speed | 60°/min |
| Specimen | 25 × 50 mm |
| Support Length | 1/4″, 1/2″, 1″ |
| Chuck Width | 1″ |
| Power Source | AC 100 V, 1-Phase, 3 A, 50/60 Hz |
| Dimension/ Weight (Approx.) | W340 × D400 × H485 mm, 20 kg |
