Evaluating stiffness of woven fabrics (cantilever method) | CANTILEVER FABRIC STIFFNESS TESTER / No.476

• No.476 CANTILEVER FABRIC STIFFNESS TESTER
• No.476-M CANTILEVER FABRIC STIFFNESS TESTER (ELECTRIC)

Overview of CANTILEVER FABRIC STIFFNESS TESTER

This tester is used to evaluate the stiffness of textile according to the 45° cantilever method.
Placing one end of the test specimen on the top of the slide and sliding the test specimen towards the slide, the operator is to read the position where the other end of the test specimen touches the 45° slide.

Reference Standards

JIS (L1018), L1096, (JASO)

Specification

Specifications are subject to change without notice.
Type	No.476
Test Sample	20×150 mm
Scale	0–150 mm (graduation 1 mm)
Angle of Incline	45°
Accessories	Sample weight
Dimensions and Weight (Approx.)	W225×D125×H100 mm, 2.5 kg

---

Overview of CANTILEVER FABRIC STIFFNESS TESTER (ELECTRIC)

This tester is used to evaluate the stiffness of textile according to the 45° cantilever method.
Placing one end of the test specimen on the top of the slide and sliding the test specimen towards the slide, the operator is to read the position where the other end of the test specimen touches the 45° slide.

Reference Standards

JIS (L1018)、L1096、(JASO)

Specification

Specifications are subject to change without notice.
Type	No.476-M
Test Sample	30×200 mm
Scale	0–200 mm (graduation 1 mm)
Angle of Incline	41.5˚, 45˚ (replace the inclined block to change angle)
Test Speed	60–300 mm/min
Accessories	Inclined block (41.5˚, 45˚), sample weight,open-end wrench
Power Source	AC 100 V 1-phase 3 A 50/60 Hz
Dimensions and Weight (Approx.)	W500×D250×H270 mm, 16 kg
