No.524 PRINT INK DRYING TESTER
JIS K5701-1
- This tester is used to evaluate the drying characteristics of planographic ink.
- Wrapping the testing paper to the circumference of the drum which rotates at a constant speed and applying constant load, the operator is to measure the offset condition and the drying time of the test specimen.
Specification
| Specifications are subject to change without notice. | |
| Measuring Time | Max. 15 hr, Max. 1.5 hr |
| Drum Rotation Speed | 1/10 rpm, 1 rpm |
| Rotating Drum | Outer Diameter φ103 ± 1 mm, L300 mm |
| Gear Feed Speed | 0.3 mm/min, 3 mm/min |
| Gear Pressing Load | 7.36 ± 0.20 N (750 ± 20 gf) |
| Accessories | Time Scale |
| Power Source | AC 100 V, 1-Phase, 10 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | W620 × D250 × H310 mm, 25 kg |
