No.551-AUTO CROSS CUT MACHINE Operation & motion video
No.551 CROSS CUT MACHINE（AUTOMATIC）
JIS D0202、(K5400)、K5600-5-6、ISO 2409
- This is a fully automated cross cutting machine, which cuts paint-coated samples in a grid pattern (aka cross cut method).
- The cutting blade is set perpendicular to the sample, and the necessary weights are added to the blade.
- All cuts penetrate through the paint coatings and to the surface of the substrate. Once the cuts are made, the specimen is brushed, then applied with standard-specified tape. The tape is peeled within 5minutes after it is applied.
- The number of cuts and the pitch can be set via touch panel. No.551-AUTO-2 is additionally featured with 90° automatic specimen rotation. Cuts are more precise compared to that of manual cross cutting.
Specification
Specifications are subject to change without notice.
| Specifications are subject to change without notice. | ||
| Model |
No.551-AUTO-1
|
No.551-AUTO-2
|
| Specimen Table |
240 × 200 mm
|
|
|---|---|---|
| 90° Rotation | Manual | Automatic |
| Max. Specimen Size |
210 × 200 mm
(Cross Cut Area 140 × 140 mm) |
|
| Scratching Pitch |
Chosen from 0.5, 1.0, 1.5, 2.0, 3.0 mm
|
|
| Scratching Number |
Variable by Touch Panel (Standard: 6, 11 lines)
|
|
| Scratching Speed |
5 to 150 mm/s (Unit 0.1 mm/s)
|
|
| Test Load |
Initial 10 gf to 400 gf
Deadweight Balance + Additional Weights Chosen from 10 to 400 gf, 50 to 1,050 gf |
|
| Scratcher |
Cutter
|
|
| Safety Device |
Emergency Stop SW
|
|
| Accessories |
Weight*, Height Adjustment Gauge, Cutter Blade Holder,
Spare Cutter Blade, Cutter Blade Setting Jig, Hexagon Wrench, Spanner Wrench |
|
| Option |
Needle, Needle Holder, Sapphire Needle,
Sapphire Needle Holder, Safety Cover |
|
| Power Source |
AC 100 V, 1-Phase, 10 A, 50/60 Hz
|
|
| Dimensions/ Weight (Approx.) | Safety Cover Not Attached W630 × D750 × H700 mm/ 90 kg Safety Cover Attached W630 × D750 × H760 mm/ 95 kg |
Safety Cover Not Attached W630 × D750 × H700 mm/ 90 kg Safety Cover Attached W630 × D750 × H760 mm/ 95 kg |
*Specifications may differ according to the selected Weights.
