No.514 PAINT FILM BENDING TESTER
JIS (K5400), K5600-5-1, ISO 1519
- This tester is used to evaluate the bending endurance of paint and varnish coated film according to the cylindrical form mandrel method.
- The operator is to place the coated film testing board on the outer side and bending at a speed so that it takes 1 to 2 seconds to bend the testing board 180°.
- The operator is then to see cracks and peels of the coated film.
Specification
| Specifications are subject to change without notice. | |
| Model | No.514 |
| Test Plate | 150 × 50 × T0.3 mm or Less |
| Bending Angle | 180° |
| Mandrel Diameter | φ2, φ3, φ4, φ5, φ6, φ8 and φ10 mm: 7 kinds |
| Supporting Plate Thickness | 1, 2, 2.5, 3, 3.5 and 4 mm: 6 kinds |
| Dimensions/ Weight (Approx.) | W100 × D150 × H40 mm, 8 kg (Including Case) |
No.514-TYPE1 PAINT FILM BENDING TESTER
JIS (K5400), K5600-5-1, ISO 1519
- This tester is used to evaluate the bending endurance of paint and varnish coated film according to the cylindrical form mandrel method.
- The operator is to place the coated film testing board on the outer side and bending at a speed so that it takes 1 to 2 seconds to bend the testing board 180°.
- The operator is then to see cracks and peels of the coated film.
Specification
| Specifications are subject to change without notice. | |
| Model | No.514-TYPE1 |
| Test Plate | 100 × 50 × T0.3 mm or Less |
| Bending Angle | 180° |
| Mandrel Diameter | φ2, φ3, φ4, φ5, φ6, φ8, φ10, φ12, φ16, φ20, φ25 and φ32 mm: 12 kinds |
| Supporting Plate Thickness | 3.5, 6, 8, 10, 11, 12, 13, 13.5, 14, 14.5 and 15 mm: 11 kinds |
| Dimensions/ Weight (Approx.) | W100 × D150 × H40 mm, 8 kg |
Contact Us
For over 70 years, Yasuda Seiki’s testing machines have supported quality control and research & development across various industries, meeting the diverse needs of our clients.
Other products
- No.579 Barcoater 【For making a surface of ink or colorant】 We handle many types based on the coating thickness!
- No.258-ZA IMPACT TESTER (FULL AUTOMATIC)
