No.202 LEATHER CONTRACTION TEMPERATURE TESTER
JIS K6550, K6552
- This tester is used to measure the submerge heat shrinkage temperature of leather.
- The operator is to attach the test specimen to the upper and lower Chuck with prescript load and submerging it into water. Then the operator is to raise the water temperature at a constant heating rate and read the temperature that the shrinkage started.
Specification
| Specifications are subject to change without notice. | |
| Specimen | 50 × (2 ± 0.5) mm |
| Shrinkage Scale | Left – Right: 0 to 90° (1° = 0.25 mm) |
| Weight Load | 5 gf, 10 gf, 20 gf, 30 gf |
| Heat-Up Speed | 3 to 5 °C/min |
| Accessories | Glass Beaker, L-shape Thermometer: 2 pcs |
| Power Source | AC 100 V, 1-Phase, 10 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | W250 × D350 × H750 mm, 25 kg |
