No.197 FLEXOMETER/BALLY FLEX TESTER
JIS K6542, K6557-8, (K6545), ISO 5402-1
- This tester is used to evaluate the strength against bending strength on the upper leather of shoes and other thin leather.
- Folding the test specimen and attaching it to the Chuck while giving it a 22.5° bending stress for a prescript number of times, the operator is to see and evaluate the damage to the test specimen.
- The tester can also be assorted with a low temperature oven (L type).
Specification
| Specifications are subject to change without notice. | |
| Model | No.197 FLEXOMETER/BALLY FLEX TESTER |
| Hangings | 12 Hangings |
| Specimen | 70 × 45 mm |
| Flexing Angle | 22.5° |
| Flexing Speed | 100 ± 5 times/min |
| Counter | 8 Digits Preset Counter, 9 Digits Total Counter |
| Temperature Range | – |
| Power Source | AC 100 V, 1-Phase, 10 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | W530 × D760 × H500 mm, 75 kg [Separate Model]Tester Body: W610 × D710 × H360 mm, 70 kg Control Box: W210 × D450 × H290 mm, 8 kg |
No.197-L FLEXOMETER/BALLY FLEX TESTER (WITH REFRIGERATING MACHINE)
JIS K6542, K6557-8, (K6545), ISO 5402-1
- A low temp. chamber installed version is also available for low temp. testing.
Specification
| Specifications are subject to change without notice. | |
| Model | No.197-L FLEXOMETER/BALLY FLEX TESTER (WITH REFRIGERATING MACHINE) |
| Hangings | 12 Hangings |
| Specimen | 70 × 45 mm |
| Flexing Angle | 22.5° |
| Flexing Speed | 100 ± 5 times/min |
| Counter | 8 Digits Preset Counter, 9 Digits Total Counter |
| Temperature Range | -35 to 60 °C (Refrigerator) |
| Power Source | AC 200 V, 3-Phase, 30 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | W1,300 × D1,150 × H1,450 mm, 428 kg |
