No.416 CROCK METER
JIS K6404-16, (K6547), L0849, (L0862), ISO 105-X12
- This tester is used to evaluate the color fastness of textile products, leather, rubber, and plastic against abrasion.
- The operator is to place the test specimen on the flat surface and the test specimen is to be abraded with an abrading head which is attached with a white cloth.
- After the test has been finished, the operator is to judge the degree of color fastness according to the gray scale.
Specification
| Specifications are subject to change without notice. | |
| Specimen | 140 × 50 mm |
| White Cotton Cloth | 50 × 50 mm |
| Weight Load | 8.83 N (900 gf) or 9 N ± 0.2 N |
| Abrading Head | φ16 ± 1 mm |
| Abrading Distance | 100 mm |
| Abrading Speed | 60 times/min |
| Counter | 6 Digits Preset Counter |
| Option | Light Load Spec, Safety Cover |
| Power Source | AC 100 V, 1-Phase, 3 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | W260 × D640 × H260 mm, 16 kg |
