No.476 CANTILEVER FABRIC STIFFNESS TESTER
JIS (L1018), L1096, (JASO)
- This tester is used to evaluate the stiffness of textile according to the 45° cantilever method.
- Placing one end of the test specimen on the top of the slide and sliding the test specimen towards the slide, the operator is to read the position where the other end of the test specimen touches the 45° slide.
Specification
| Specifications are subject to change without notice. | |
| Type | No.476 CANTILEVER FABRIC STIFFNESS TESTER |
| Specimen | 20 × 150 mm |
| Scale | 0 to 150 mm (Scale 1 mm) |
| Inclination Angle | 45° |
| Accessories | Weight |
| Dimensions/ Weight (Approx.) | W225 × D125 × H100 mm, 2.5 kg |
No.476-M CANTILEVER FABRIC STIFFNESS TESTER (ELECTRIC)
JIS (L1018)、L1096、(JASO)
- This tester is used to evaluate the stiffness of textile according to the 45° cantilever method.
- Placing one end of the test specimen on the top of the slide and sliding the test specimen towards the slide, the operator is to read the position where the other end of the test specimen touches the 45° slide.
Specification
| Specifications are subject to change without notice. | |
| Type | No.476-M CANTILEVER FABRIC STIFFNESS TESTER (ELECTRIC) |
| Specimen | 30 × 200 mm |
| Scale | 0 to 200 mm (Scale 1 mm) |
| Inclination Angle | 41.5° , 45°(Attachment) |
| Accessories | Inclination Angle Attachment (41.5°, 45°), Weight, Single Ended Wrench |
| Power Source | AC 100 V, 1-Phase, 3 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | W500 × D250 × H270 mm, 16 kg |
Inquiry Form
Contact Us For over 70 years, Yasuda Seiki’s testing machines have supported quality control and research & development across various industries, meeting the diverse needs of our clients.
Other products
- No.528 Sutherland Type Rub Tester【Yasuda Seiki】To evaluate the abrasion endurance and color transfer characteristic・feathering of paper of planographic ink
- No.197 FLEXOMETER/BALLY FLEX TESTER【YASUDA SEIKI】For the tester to evaluate the bending strength on thin leather.
- No.304-TP Mullen High-Pressure Type Bursting Strength Tester【YASUDA SEIKI】To evaluate the bursting strength of paper・paper board・rubber・plastic
- No.516 Erichsen Cupping Tester【YASUDA SEIKI】For the tester to evaluate the Cupping Endurance of the coated film
- No.260 For Measuring Compression Residual Strain of Urethane Foam【YASUDA-SEIKI】 FOAM RUBBER REPEATED COMPRESSION TESTER
- No.268 ULTRA-LOW TEMP. UNIVERSAL IMPACT TESTER 【YASUDA-SEIKI】 Capable of Producing -70℃ Conditions for Low Temp. Impact Testing
- No.140-SAS AUTOMATIC CAPILLARY RHEOMETER 【YASUDA-SEIKI】For Evaluating the Flow Characteristics of Plastic Materials
- No.173-S CUT-THROUGH TESTER (FOR ENAMELED WIRE)｜YASUDA SEIKI SEISAKUSHO LTD. providing you the best material testing equipment.
