No.199 BREAKDOWN VOLTAGE TESTER
JIS C2110, (C3003), C3216-5, IEC-60851-5
- This tester is for evaluating the dielectric strength (volt endurance/ volt destruction) of solid electric insulating material.
- By exchanging the electrodes, the tester can also be used for board, sheet, textile, film, tape, tube, varnish, and paint.
- Recent applications also include insulating film in lithium-ion batteries.
- After setting the specimen between the two electrodes, voltage is applied mid-air or in-bath until the specimen insulation destructs.
- The results are evaluated either by the insulation strength or destruction voltage level.
- The tester is capable of both the short-time test and step-by-step test.
- The tester can also be used for enamel coatings using the twistpair method by exchanging the electrodes.
Specification
| Specifications are subject to change without notice. | |
| Capacity | 0.5 to 10 kVA |
| Maximum Output Voltage | AC 5 to 80 kV |
| Specimen | L500 mm (Twisting L 120mm), φ0.05 〜 φ3.2 mm |
| Test Method |
Oil Bath or Air Bath |
| Standard Equipments | A-meter, V-meter, Volt-slider, Programmed Voltage Raising Device, Breakdown Current Regulator |
| Option | Timer, Software |
| Safety Device | Safety Cover with Interlock Attached, Earth-Leakage Breaker, Upper Voltage Limit, Emergency Stop SW, Warning Indicator & Buzzer |
| Electrode | Selected by Specimen |
| Power Source | AC 200 V, 1-Phase, 15 to 50 A, 50/60 Hz |
| Dimensions/ Weight (Approx.) | Differ by Specifications. |
No.199-T TWISTING DEVICE (FOR BREAKDOWN VOLTAGE TEST)
JIS (C3003), C3216-5, IEC-60851-5
- This device is used for enabling the twistpair method for enamel insulation testing, particularly for the No.199 BREAKDOWN VOLTAGE TESTER.
- The test specimen is folded in half, attached to the chucks of the device, and twisted at the set tension for twistpair method testing.
- The No.199 BREAKDOWN VOLTAGE TESTER can be used for testing.
Specification
| Specifications are subject to change without notice. | ||
| 1 Hanging | 3 Hangings | |
| Operation | Manuel | Electric ( Station-Linked ) |
| Weight Load | 0.029 〜 108N | 0.029 〜 108N |
| Corresponding Wire Diameter |
0.4 to 1.2 mm | 0.4 to 1.2 mm |
| Twisting Speed | ― | 60 twists/min |
| Safety Device | ― | Interlock Switch, Safety Cover, Leakage Breaker, Emergency Stop Switch |
| Accessories | Weight 39 N, Spanner | ― |
| Power Source | ― | AC 100 V, 1-Phase, 15 A, 50/60 Hz |
| Dimensions/Weight(Approx. ) | W250 × D250 × H750 mm, 20 kg | Differ by Specifications. |
